Egress Allowlist
As part of our heightened security posture and constant drive to full zero trust, we deny egress from our clusters by default and can add exceptions to an allowlist through configuration, pending approval. We have created a request form in JSD to help streamline this approval. As you likely know, your architecture diagram that is required for CtF's requires you to identify all external connections and associated ports. We will also implement these security practices in our staging cluster for consistency and security of our environment. In this case, external connections means anything that is deployed outside the kubernetes namespace that your container is deployed to – this includes external connections to the open internet, other DoD ATO'd systems (i.e., external data sources), and internal to a P1 environment but deployed by a different app or team.
Examples
Here are a couple of examples of external connections that would require a configuration update for your application. Regardless of which examples hits home for you, the request process is the same. See the links at the bottom of the page.
NOTE: Connecting to services at different Impact Levels requires additional approval and may not be possible in some cases.
Internal to P1 Environment
Connection to DSOP Cluster:
Let's say your application needs to pull information from the P1 deployed instances of Jira or Gitlab for some sort of metrics collection. Since your application will be deployed in our mission clusters (staging and prod) which are in different VPCs from where we host Jira and Gitlab (our DSOP clusters), you would need an egress request to make that connection.
Connecting to a Service from a Different Mission App in the Same Cluster:
In this scenario, you need to connect to a different application that is also deployed by P1 and the PB team for information. This could happen if you are part of the same software factory and hitting the API from a sister team. Even though they are deployed in the same cluster as you, you would need to submit an egress request because the service you are connecting to is deployed in a different namespace.
External to P1 Environment
It may be the case that your application needs to connect to something as an external data provider, such as the Unified Data Library (UDL). The UDL is hosted outside of P1 Environments so this would require an egress request. To process these we will need to assess security impact to connect to an external environment and need you to provide an Authorization to Connect (ATC) which is some processing you need to do in support of your CtF process in compliance with our Authority to Operate (ATO). Please reach out to your Cyber Applications Team (CAT) representative if you have questions.
NIPR Guidance
Connections to the NIPR boundary are not explicitly allowed from Platform One/Party Bus. Customers wanting to make a connection into the NIPR boundary will need to note this in the tickets created for egress requests (see below). The process for allowing traffic into the NIPR boundary involves the P1 team filling out a ports and protocols form (PPS) as well as working with DISA to allow this traffic. Please be ready to answer these three questions when creating a ticket for egress to NIPR
- What is the FQDN of your Party Bus app?
- Do you want access from both Staging and Prod?
- Is the endpoint on NIPR cloud hosted or not?
Making the Request
Errors you would see suggesting you might need to make this request
In our testing, we saw two different errors that popped up as we tried to hit endpoints that weren't on the allow list:
- SSL Certificate errors - this is due to Istio terminating the communication. The SSL portion is a bit of a red herring, but it points towards Istio being the source of the error.
- Bad Gateway (502) errors.
Submitting requests
We have Jira Service Desk Forms built for staging and production environments, respectively. Please remember after submitting your request to update your architecture diagram to ensure a smooth Certificate to Field process!
Production Egress Request Staging Egress Request
